Product Description
Custom Autosound Slidebar Radio for '67-'72 Chevy Truck
When it comes to technology, the slidebar is designed with the best features available. First off, it has an iPod dock. Navigation of the iPod is all controlled from the buttons on the radio. The slidebar stereo also has a USB port at the back that allows you to plug in a USB flash drive for playbacks of MP3 files, an auxiliary audio input for any portable player or satellite radio, a CD changer controller and the ability to add Bluetooth with Blukit adapter. This stereo allows you to have hands free phone calls. It is the only in-dash radio that Custom Autosound offers that has a subwoofer pre-out for increased sound, a digital tuner with 300 watts of power, four channel pre-amp outputs and four pre-out jacks for optional amplifiers. The slidebar radio is based on the AM-FM RDS system, with 25 pre-sets, Bass/Mid/Treble tone control, Loudness compensation, DSP EQ, front and rear fader, and left right balance. Lastly, the stereo features a USA/Euro tuner, and power antenna lead making it the best stereo option for your Chevy truck.
• AM-FM RDS tuner with 25 pre-sets (15-FM / 10AM)
• RDS tuner shows station / song / artist on LCD display
• 300 Watts Peak
• 7 LCD color choices (user selectable - white/red/blue/cyan/green/yellow/pink)
• LCD dimmer control
• Bluetooth Option Available (#Blukit)
• iPod doc and control (Control your iPod from the buttons on the radio)
• USB Port for Flash Drive MP3/WMA Playback
• Direct 6 CD Changer Control
• Alpha Numeric Display for MP3/WMA/ iPod files
• Electronic Tuning and Volume Control w/Last Volume Memory
• Bass / Mid / Treble Tone Control
• Loudness compensation
• DSP EQ
• Front Rear Fader
• Left Right Balance
• Digital Clock
• 2 Channel RCA Auxiliary Input for Satellite etc.
• 4 Channel RCA Pre-outs
• Subwoofer Line out w/Level and x-over Adjustments
• USA/Euro Tuner
• Power Antenna Lead
Slidebar Radio for '67-'72 Chevy Truck: Your Questions Answered
Which vehicles is the Slidebar Radio for '67-'72 Chevy Truck listed for?
In our year/make/model search it's listed for the 1967-1972 Chevy Truck. Use the vehicle search to confirm your exact car.
What can I add to my Slidebar Radio for '67-'72 Chevy Truck order?
The options on this page let you add a front dual voice coil speaker, a rear 6x9 speaker pair (Custom Autosound 6x9 Speaker Pair and Upgraded Pioneer Speaker Pair), and an antenna (Hideaway Antenna and Power Antenna).
Is there a CD or Bluetooth upgrade?
Yes. The options include Single Slave CD.
What is special about the display?
This Slidebar Radio for '67-'72 Chevy Truck uses Custom Autosound's DigaDial or Slidebar interface, which is designed to keep a period look while adding modern features.
Slidebar radio specifications
- High power: max 300 watts (45W × 4 output channels per Slidebar user manual)
- AM/FM with RDS; 25 presets
- 7 selectable LCD color choices; hideaway digital display with classic slidebar look
- USB MP3/WMA player; iPod dock charge and control (30-pin cable; USB iPod/iPhone not supported)
- CD changer controller (Custom Autosound CD1 or USA-CD60)
- Auxiliary input; RCA pre-outs (2 pair) plus subwoofer line out with crossover
- Front/rear fader; left/right balance; bass / mid / treble; DSP EQ; loudness; clock
- Power antenna lead; last-volume memory
- Direct fit to OEM dash opening (vehicle-specific conversion)
- 12 V negative-ground only; speaker impedance 4–8 Ω
- Optional BluKit Bluetooth adapter for streaming / hands-free
- Custom Autosound 2-year parts / 1-year labor limited warranty (in-dash radios)
Slidebar wiring and tech tips
Typical Custom Autosound harness (confirm against the printed diagram that ships with your unit):
| Function | Wire |
|---|---|
| Ignition / ACC +12V | Red |
| Memory / constant +12V | Yellow |
| Ground | Black |
| Power antenna / remote | Blue (fully automatic antennas only) |
Important: Both red and yellow must be connected. Do not connect the blue lead to a semi-automatic (knob/switch) factory antenna — that can damage the radio (per Slidebar manual).
Speakers: 4–8 Ω; do not common speaker negatives to chassis ground. Rear mounting strap required (omission voids warranty per manual).
Vehicle: 67-72 Chevy Truck. Disconnect the battery before wiring. Vintage Car Radio does not install.
Slidebar manuals
Vintage Car Radio does not offer installation.
Custom Autosound Limited Warranty
Per the Custom Autosound Slidebar / in-dash radio user manuals, parts are covered for 2 years and labor for 1 year from original purchase for defects in materials and workmanship (original purchaser).
Warranty does not cover antenna problems, installation damage, misuse, or unrelated vehicle electrical issues. Call Vintage Car Radio at 844-802-4499 or 574-226-6676 for help coordinating service.
Vintage Car Radio does not offer installation.
FAQ — 67-72 Chevy Truck Slidebar
Will this fit without cutting the dash?
Slidebar conversions are made for the OEM opening for 67-72 Chevy Truck. Compare your dash to the product photos.
Bluetooth?
Bluetooth is available via the optional Custom Autosound BluKit adapter (unless your package already includes it).
Do you install?
No.
Warranty?
Custom Autosound in-dash radios: 2-year parts / 1-year labor per the Slidebar user manual.
Need help?
844-802-4499 or 574-226-6676.
