Product Description
Custom Autosound USA-850 for a 1940-49 Oldsmobile
Upgrade Your 1940-49 Oldsmobile with the Custom Autosound USA-850
Driving a 1940-49 Oldsmobile is like stepping back in time to an era of classic automotive craftsmanship and elegance. While these vintage vehicles are cherished for their design and history, their original radios often lack the modern features that today’s drivers want. That’s where the Custom Autosound USA-850 comes in. Designed specifically for classic cars, this radio provides a factory-fit look while offering the latest in audio technology, making it the perfect upgrade for your Oldsmobile.
Classic Appearance, Modern Sound
The USA-850 is built to maintain the original style of your 1940-49 Oldsmobile’s dashboard while delivering an enhanced audio experience. It features a vintage push-button design that preserves the car’s timeless aesthetic, but beneath the classic exterior, you’ll find a high-tech sound system with all the modern conveniences you need.
Key Features of the USA-850
‚úî AM/FM Digital Tuner – Access your favorite radio stations with strong reception and clear sound quality.
‚úî Bluetooth Connectivity – Stream music wirelessly from your smartphone, tablet, or other Bluetooth-enabled devices.
‚úî USB & AUX Inputs – Connect MP3 players, flash drives, or other external devices for versatile audio playback.
‚úî 300-Watt Power Output – Provides rich, high-quality sound to enhance your driving experience.
‚úî CD Changer Compatibility – Supports an optional CD changer for those who still enjoy their CD collection.
Why Choose the USA-850?
With the Custom Autosound USA-850, you don’t have to choose between preserving your 1940-49 Oldsmobile’s classic look and enjoying modern sound quality. Get yours today at Vintage Car Radio and enjoy the perfect blend of retro styling and cutting-edge audio performance!
Specifications
• 4 programmable screen options
• Working analog dial
• Custom Fit In Dash
• 6-volt RCA Pre-Outs and dual subwoofer pre-outs
• DSP EQ
• Subwoofer control
• Bass, treble, mid
• Fader/balance
• Loudness on/off
• CD Controller
• RCA AUX in
• Bluetooth
• 75W X 4 Peak (300W max)
• PLL Tuner
• Power Supply 12 VDC negative ground
• Speaker impedance 2-8
• 4 lbs shipped
• Shipping box 12 X 11 X 5
• Fits all CAS current applications (400+)
Frequently Asked Questions About the USA-850 for a 1940-49 Oldsmobile
Is this radio made specifically for the 1940-49 Oldsmobile?
This listing is the version made for the 1940-49 Oldsmobile, designed to go into the original dash opening. Custom Autosound says its radios fit without altering or cutting the original dash.
Is there a CD or Bluetooth upgrade?
Check the CD options on this page, which include Single Slave CD.
What can the USA-850 do?
Custom Autosound rates it at 75 watts x 4 peak (300 watts max), with 6-volt RCA pre-outs and dual subwoofer pre-outs. You can adjust bass, treble and midrange or choose a DSP EQ preset (Flat, Classic, Pop or Rock).
My 1940-49 Oldsmobile is 6-volt or positive ground. Can I still use this?
What if my 1940-49 Oldsmobile has air conditioning?
The Factory Air option tells us which dash layout your 1940-49 Oldsmobile has, so pick Yes if it has factory A/C.
What do I get with the USA-850 in my 1940-49 Oldsmobile?
It streams music and takes calls over Bluetooth. The USB port plays MP3, WMA and FLAC files and also charges your phone.
USA-850 specifications
- DigaDial selectable display (including working analog-style dial and digital RDS views)
- Bluetooth built in (streaming and hands-free calling)
- 300 watts peak power (75W x 4 peak)
- AM/FM stereo tuner with RDS
- 25 presets
- USB port for MP3/WMA/FLAC/WAV playback and phone charging
- Rear RCA auxiliary input
- Direct control for optional CD-1
- 6-volt RCA pre-outs plus dual subwoofer pre-outs
- Bass, midrange, and treble; DSP EQ (Flat, Classic, Pop, Rock)
- Front/rear fader and left/right balance; loudness
- Power antenna lead; digital clock
- 12V negative-ground; 2–8 ohm speakers
- Designed for original classic dash openings (vehicle-specific faceplate)
- Custom Autosound 2-year manufacturer warranty
USA-850 wiring and tech tips
Use this as a head-unit reference for power, ground, antenna, speakers, and amplifier connections. Always match the printed diagram that ships with your unit if it differs.
Power and ground (typical Custom Autosound harness)
| Function | Wire color |
|---|---|
| Ignition / ACC +12V | Red |
| Battery / constant +12V | Yellow |
| Ground | Black |
| Power antenna | Blue |
Ignition and power-antenna leads are commonly fused at 1A on the harness—confirm against the guide that ships with your radio.
Speaker wiring (typical)
| Speaker | Wire color |
|---|---|
| Left front + / − | White / White-Black |
| Right front + / − | Gray / Gray-Black |
| Left rear + / − | Green / Green-Black |
| Right rear + / − | Violet (or Purple) / Violet-Black |
USA-850 extras
Expect antenna, USB (playback and phone charge), Bluetooth microphone, optional CD-1 control, 6V front/rear RCA pre-outs, and dual subwoofer pre-outs. Use the rear RCA AUX for a wired player. Pick your DigaDial display style in the radio menu after power-up.
Suggested order for a 1940-1949 Oldsmobile
- Disconnect the vehicle battery before any wiring.
- Connect ground first, then constant (yellow) and ignition (red).
- Connect the antenna plug and the blue power-antenna lead if your car has a power antenna.
- Wire all four speakers, matching polarity.
- If using an amplifier, run RCA cables from the front/rear (and sub on USA-740/USA-850) pre-outs.
- Reconnect the battery and test radio, speakers, and charging system voltage.
Tech tips for 1940-1949 Oldsmobile
- This radio is sold for the factory Oldsmobile opening used in 1940-1949 models—do not cut a modern DIN rectangle if you want a stock look.
- A poor ground is the most common cause of whine or weak audio; scrape paint at the ground point and use a star washer.
- If AM reception is weak, check the antenna mast, cable continuity, and that the antenna plug is fully seated.
- Vintage Car Radio does not install radios. If you are not comfortable with 12V wiring, use a qualified installer.
USA-850 manuals
Download the manufacturer guide for operation, safety, and the official wiring diagram. You can also browse our full library on the Manuals page.
Vintage Car Radio does not offer installation. The manuals are for do-it-yourself reference or to share with your installer.
Two-Year Custom Autosound Warranty
All Custom Autosound radios sold by Vintage Car Radio are backed by a 2-year manufacturer warranty from Custom Autosound.
Radios are checked before shipping. If something is wrong out of the box or under warranty, call us at 844-802-4499 or 574-226-6676 and we will help coordinate with the manufacturer.
Vintage Car Radio does not offer installation services. Refer to the Manuals and Wiring / Tech Tips sections for manufacturer guidance, or use a qualified car-audio installer.
FAQ — 1940-1949 Oldsmobile USA-850
Will this fit my 1940-1949 Oldsmobile without cutting the dash?
It is built for the original radio opening used on 1940-1949 Oldsmobile models. Compare your dash opening and bezel to the product photos. We do not modify dashes in-house.
Does this radio have Bluetooth?
Yes—Bluetooth is built into the USA-850 for streaming and hands-free calling. The DigaDial display also offers selectable classic dial and digital views.
Do I need an amplifier?
Many owners run speakers directly from the radio. Pre-outs are there if you want more volume or a subwoofer later.
Do you install the radio?
No. Vintage Car Radio ships the unit and documentation; installation is DIY or by a shop you choose.
What is the warranty?
Custom Autosound radios include a 2-year manufacturer warranty. See the Warranty section for details.
Need help?
Call 844-802-4499 or 574-226-6676.
