Product Description
When you hear the words
"The Boss," you know people are talking about the classic 1967-73 Mercury Cougar. It was a great car with classic lines, and everyone knew it was the Boss.
Add a classic-style radio like the USA-230 and you only raise its status. The Boss deserves a great radio in its dash, and the USA-230 is one.
Inside This Great Radio
With the Custom Autosound USA-230, you're not getting just another device that plays music. You're getting a top-notch radio worthy of a 1967-73 Mercury Cougar.
16 presets (12 FM, 4 AM) keep your favorite stations close, and 200 watts of power drive your speakers.
It also has a 4-way fader, 4-channel RCA pre-outs, a rear aux input and a digital clock. And its electronic tuner helps you find AM/FM stations with ease.
To top it off, a power antenna lead helps you pull in stations clearly. When you drive the Boss, your radio should be in the same class.
A Boss in Its Own Right
That's what makes the Custom Autosound USA-230 a great radio for your classic 1967-73 Mercury Cougar. It's the Boss of radios and a perfect match for the car.
Once it's in your car, your ears are in for great sound.
This radio features:
● AM/FM stereo
● 200 Watts (4x50)
● Auxiliary Input (RCA Rear) RCA to 1/8" pin jack included
● Digital Clock
● Electronic Tuner
● 16 presets (12 FM, 4 AM)
● 4 Channel RCA Pre-outs
● 4-way fader
● Power Antenna Lead
Available with a black or chrome face
Questions About the 1967-73 Mercury Cougar USA-230 In Dash AM/FM
Will it fit my 1967-73 Mercury Cougar without cutting the dash?
This version is built for the 1967-73 Mercury Cougar and is made to fit the factory radio opening. Custom Autosound says its radios fit without altering or cutting the original dash.
How does the USA-230 handle phone audio and connections?
There's a rear RCA auxiliary input, and Custom Autosound includes an RCA to 1/8" pin jack cable for phones, MP3 players or satellite tuners. The electronic tuner stores 16 presets, 12 FM and 4 AM.
Can I buy speakers and an antenna at the same time?
The options on this page let you add a front dual voice coil speaker, a rear 6x9 speaker pair (Custom Autosound 6x9 Speaker Pair and Upgraded Pioneer Speaker Pair), kick panels (W/Speakers, W/O Speakers, and Pioneer Upgrade), and an antenna (Hideaway Antenna and Power Antenna).
Will it work with a 6-volt system?
Choose your system under Voltage (12 volt and 6 volt) and Ground (Positive and Negative) when you order.
What if my 1967-73 Mercury Cougar has air conditioning?
The Factory Air option tells us which dash layout your 1967-73 Mercury Cougar has, so pick Yes if it has factory A/C.
What do I get with the USA-230 in my 1967-73 Mercury Cougar?
It skips the USB port, iPod dock and CD changer control found on the USA-630, but keeps the same look. It's rated at 200 watts (4x50) and has 4-channel RCA pre-outs, so you can add an outboard amplifier later.
USA-230 specifications
- 200 watts peak power (50W x 4)
- AM/FM stereo tuner
- RCA auxiliary input
- 12 FM and 4 AM presets
- Electronic tuning and volume
- 4-channel RCA pre-outs for an external amplifier
- Separate bass and treble controls
- 4-way fader and left/right balance
- Power antenna lead
- Designed for original classic dash openings (no DIN cut required for vehicle-specific faceplates)
- Custom Autosound 2-year manufacturer warranty
USA-230 wiring and tech tips
Use this as a head-unit reference for power, ground, antenna, speakers, and amplifier connections. Always match the printed diagram that ships with your unit if it differs.
Power and ground (typical Custom Autosound harness)
| Function | Wire color |
|---|---|
| Ignition / ACC +12V | Red |
| Battery / constant +12V | Yellow |
| Ground | Black |
| Power antenna | Blue |
Ignition and power-antenna leads are commonly fused at 1A on the harness—confirm against the guide that ships with your radio.
Speaker wiring (typical)
| Speaker | Wire color |
|---|---|
| Left front + / − | White / White-Black |
| Right front + / − | Gray / Gray-Black |
| Left rear + / − | Green / Green-Black |
| Right rear + / − | Violet (or Purple) / Violet-Black |
USA-230 extras
Use the rear RCA AUX for a wired player. Pre-outs support adding an amplifier later without replacing the radio.
Suggested order for a 1967-1973 Cougar
- Disconnect the vehicle battery before any wiring.
- Connect ground first, then constant (yellow) and ignition (red).
- Connect the antenna plug and the blue power-antenna lead if your car has a power antenna.
- Wire all four speakers, matching polarity.
- If using an amplifier, run RCA cables from the front/rear (and sub on USA-740/USA-850) pre-outs.
- Reconnect the battery and test radio, speakers, and charging system voltage.
Tech tips for 1967-1973 Cougar
- This radio is sold for the factory Cougar opening used in 1967-1973 models—do not cut a modern DIN rectangle if you want a stock look.
- A poor ground is the most common cause of whine or weak audio; scrape paint at the ground point and use a star washer.
- If AM reception is weak, check the antenna mast, cable continuity, and that the antenna plug is fully seated.
- Vintage Car Radio does not install radios. If you are not comfortable with 12V wiring, use a qualified installer.
USA-230 manuals
Download the manufacturer guide for operation, safety, and the official wiring diagram. You can also browse our full library on the Manuals page.
Vintage Car Radio does not offer installation. The manuals are for do-it-yourself reference or to share with your installer.
Two-Year Custom Autosound Warranty
All Custom Autosound radios sold by Vintage Car Radio are backed by a 2-year manufacturer warranty from Custom Autosound.
Radios are checked before shipping. If something is wrong out of the box or under warranty, call us at 844-802-4499 or 574-226-6676 and we will help coordinate with the manufacturer.
Vintage Car Radio does not offer installation services. Refer to the Manuals and Wiring / Tech Tips sections for manufacturer guidance, or use a qualified car-audio installer.
FAQ — 1967-1973 Cougar USA-230
Will this fit my 1967-1973 Cougar without cutting the dash?
It is built for the original radio opening used on 1967-1973 Cougar models. Compare your dash opening and bezel to the product photos. We do not modify dashes in-house.
Does this radio have Bluetooth?
The USA-230 is a wired/AUX-focused radio without built-in Bluetooth. Consider a USA-740 or USA-850 if you want Bluetooth built in.
Do I need an amplifier?
Many owners run speakers directly from the radio. Pre-outs are there if you want more volume or a subwoofer later.
Do you install the radio?
No. Vintage Car Radio ships the unit and documentation; installation is DIY or by a shop you choose.
What is the warranty?
Custom Autosound radios include a 2-year manufacturer warranty. See the Warranty section for details.
Need help?
Call 844-802-4499 or 574-226-6676.
